- • Low PIM
- • Low VSWR
- • High Isolation
- •Supports 2G/3G/4G/LTE/5G
- •Widely Used for In-Building Solutions
Technical Data
Part Number |
|
GR05004 |
Electrical Specifications |
||
Frequency |
MHz |
698-3800 |
Coupling |
dB |
10 |
VSWR |
|
≤ 1.25 |
Insertion Loss |
dB |
≤ 1.1 |
Isolation |
dB |
≥ 28 |
Average Power |
W |
300 |
PIM (3rd order) @ 2 x 43dBm |
dBc |
£ -160 |
Impedance |
W |
50 ± 3 |
Mechanical Specifications |
||
Connectors Type |
|
4.3/10 Female |
Dimensions (subject to change) |
mm |
168 x 48 x 36 (Connectors Included) |
Weight (subject to change) |
kg |
0.60 |
Environmental Specifications |
||
Temperature Range |
°C |
-35 to +65 |
Relative Humidity |
% |
5 - 95 |
Application |
|
Indoor & Outdoor IP65 |
